AK2404
MP
Direct Conversion Transceiver with high interference tolerance
Direct Conversion Transceiver with high interference tolerance
MP
Description
The AK2404 is a direct conversion transceiver IC that realizes high-performance narrowband wireless communication. The receiver section incorporates an LNA, quadrature demodulator, PGA, 24-bit ΔΣ A/D Converter, and digital filter to provide a receiver with high sensitivity and high interference tolerance without the use of ceramic or SAW filter. In particular, the blocking characteristics of Δ10MHz are over 100dB (Standard: TIA603, EN 300 0861-1). The digital filter with variable bandwidth supports channel selection for multiple different wireless systems, enabling easy system design in wireless platforms. In addition, a ΔΣ fractional N-PLL synthesizer is incorporated to configure high-performance PLLs with an external VCO. The transmitter has a built-in DAC and driver amplifier. The compact QFN package of 8mm square contributes to the miniaturization of radio equipment.
Narrow Band Radio Communication | 6.25kHz / 7.5kHz /12.5kHz / 15kHz / 25kHz /etc. Modulation Method | FM / 2FSK / 4FSK / π/4 DQPSK / 16QAM / 64QAM (Modulation / demodulation needs to be externally executed except the FM demodulation.)
Key Features
-
There are 7 features. ・ Equipped with variable band channel filter ・ High sensitivity and high interference tolerance ・ AKM’s original DC offset cancellation technology: Real-time DC Offset Canceller (RDOC) ・ Support Zero IF and Low IF architecture ・ FM Detection Circuit and Noise Squelch Function ・ Modulation data input interface suitable for 2-point modulation for FM/FSK applications ・ Built-in Clock Rate Converter
Applications
-
Narrow Band Radio Communication, Analog / Digital Dual Mode Transceiver , Digital Radio System for Industrial Use, Public safety and Community / Emergency Radio System, Convenience Transceiver, Marine / Mobile Communication System, Low power / Telemeter Transmitter, Amateur Radio System
Specifications
| Part Number |
AK2404 |
|---|---|
| Description |
Direct Conversion Rx |
| RF Frequency (MIN.) [MHz] |
45 |
| RF Frequency (TYP.) [MHz] | |
| RF Frequency (MAX.) [MHz] |
960 |
| Current Consumption [mA] |
109 |
| Power Supply Voltage (MIN.) [V] |
2.7 |
| Power Supply Voltage (TYP.) [V] |
3.0 |
| Power Supply Voltage (MAX.) [V] |
3.45 |
| Other | |
| Operating Temperature [℃] |
-40 to 85 |
| Device Package |
HVQFN |
| Number of Pins |
68 |
Product Information
| Part Status |
MP |
|---|---|
| Pb Free |
Yes |
| Halogen Free |
Yes |
| MSL |
MSL2 |
| Packaging |
TAPE |
| JEDEC Standard Packaging |
Compliant |
| Minimum Order Quantity [pcs.] |
1000 |
| Replacement P/N |
Block Diagram
