Electronic Compass

The World's Smallest Class

Asahi Kasei Microdevices (AKM) is a leading manufacturer of 3-axis electronic compass using Hall element technology. We have the leading market share in the global 3-axis electronic compass for consumer applications and play a pivotal role in expanding the use of the electronic compass.

AKM electronic compass uses magnetic sensors (Hall element) with wide dynamic range and ideal linearity. The silicon monolithic structure achieves high accuracy and reliability, and it is optimized for high-volume manufacturing. Based on this technology, AKM's electronic compass can detect azimuth direction with a very high accuracy. In addition, with small and thin packaging, AKM’s electronic compass is widely used in products with limited mounting space, such as Smartphones.
AKM, with its extensive knowledge of electronic compass, is the ideal partner if you are considering to implement a “pedestrian navigation with GPS” on a cell phone, mobile tablet or mobile PC.

We provide not only hardware, but also DOE™ compensation software (winning "the Imperial Invention Award of the Japan Institute of Invention and Innovation" FY 2012), in addition to other software applications that enhance the user experience with our electronic compass.
The combination of hardware, software and technical support is an advantageous characteristic of the AKM electronic compass.

We will continue to provide the best solution through development of the compact, low-voltage and high-performance electronic compass and advanced software to our customers in the future.

Aiming to realize a wealthy life

About S-cube

S-cube is a brand name of tri-axis magnetic sensing concept presented by Asahi Kasei Microdevices (AKM).

AKM provides "Magnetic Sensing Solution" that predicts user application needs with its unique IC circuit architecture and information processing algorithm which obtains information hidden in the signal of magnetic sensors.



S3 and S-cube logos are a trademark of Asahi Kasei Microdevices Corporation in Japan, Europe and the United States.

The World's Smallest Class*

3-axis Electronic Compass for Mobile Devices

AK09918C

The World's Smallest Class

AK09918C realizes the smallest size 0.76 mm × 0.76 mm x 0.5 mm (63% size of the conventional product AK09916C) of our company while maintaining the high performance of the conventional product AK09916C.

It is housed in 0.4mm pitch 4-pin WL-CSP package. (power supply 2 pins, 2 pins for I2C communication)

[Notes]

* According to AKM as of January 1, 2017.

Lineup

Electronic Compass

Part Number
Part Status
Sensitivity (TYP.)
[μT/LSB]
Analog Power Supply
Voltage (MIN.)
[V]
Analog Power Supply
Voltage (TYP.)
[V]
Analog Power Supply
Voltage (MAX.)
[V]
Digital Interface Power
Supply Voltage (MIN.)
[V]
Current Consumption
Power-down (TYP.)
[μA]
Current Consumption
Measurement (TYP.)
[μA]
Control
Interface
Other
Operating Temperature [℃]
Device Package
Number of Pins
AK09917D
MP
0.15/0.30
1.65


1.95


1
1100 / 600 @100Hz
I2C / I3C


-30 to 85
WLCSP
5
AK09918C
MP
0.15
1.65
1.8
1.95




1100@100Hz
I2C


-30 to 85
WLCSP
4
AK09915C
MP
0.15
1.7


3.6
1.65 to VDD
3
900@100Hz
I2C / 4-wireSPI


-30 to 85
WLCSP
14
