音频模数转换器
音频芯片
AKM的音频模数转换器(ADC)采用自研的模拟与数字混合技术，不仅具备高集成度和设计自由度，而且有助于实现高清音频系统。
适用于各种音频系统，包括便携设备、高端音频设备和车载娱乐设备等。
除了旭化成微电子(AKM)的产品之外，世界上还存在有许多其他音频芯片。那么选择哪种芯片比较好呢？
我们认为，选择芯片不仅要参考产品手册上的规格指标，用起来放心也是一个重要考量因素。
在这里，我们就来介绍一下选择AKM音频芯片的理由。
舒适的在线会议
作为新的工作方式，在家办公和远程工作正在扩展。在家中参加在线会议的场景增多，与面对面的对话相比，系统能否保证清晰顺畅是许多人关注的重点，电话会议通讯质量不佳似乎使许多人感受到压力。
AKM的语音技术解决了电话会议中常见的语音问题，保证了沟通的顺畅。
真无线立体声耳机 (TWS)
近年来，真无线立体声耳机 (TWS: True Wireless Stereo) 的需求呈增长趋势。
要提高人们在聆听音乐、观看视频时的体验舒适度，以及在可穿戴设备中增加医疗辅助、互联网等多种功能，需要加强TWS机体的小型化设计、延长续航时间。
AKM为TWS应用提供合适的解决方案。
Professional Audio
- PA Equipment
- Audio Interfaces
- Measurement Instruments
- Control Systems
- Voice Conference Equipment
Home Audio
- High-end Audio
Portable Audio
- IC Recorders
- Smartphones
Automotive Audio
- Car Audio
- External Amplifiers for Car Audio
产品系列
Part Number |
Part Status |
Number of Channels |
Analog Input Type |
Bits [bit] |
Max fs [kHz] |
THD+N [dB] |
S/N [dB] |
Power Supply Voltage (MIN.) [V] |
Power Supply Voltage (TYP.) [V] |
Power Supply Voltage (MAX.) [V] |
PLL |
Microphone Amplifier |
Other |
Operating Temperature [℃] |
Device Package |
Number of Pins |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
▲
▼
|
AK5522VN |
MP |
2 |
Single/Differential |
32 |
192 |
-98 |
108 |
4.5/3.0 |
5.0/3.3 |
5.5/3.6 |
Yes |
Yes |
VELVETSOUND, Automotive grade |
-40 to 105 |
HWQFN |
24 |
AK5534VN |
MP |
4 |
Differential |
32 |
768 |
-103 |
111 (117*) |
3.0 |
3.3 |
3.6 |
VELVETSOUND, Automotive grade |
-40 to 105 |
HVQFN |
48 |
||
AK5538VN |
MP |
8 |
Differential |
32 |
768 |
-103 |
111 (120*) |
3.0 |
3.3 |
3.6 |
VELVETSOUND, Automotive grade |
-40 to 105 |
HVQFN |
64 |
||
AK5552VN |
MP |
2 |
Differential |
32 |
768 |
-106 |
115(118*) |
4.5 |
5.0 |
5.5 |
VELVETSOUND, Automotive grade |
-40 to 105 |
HVQFN |
48 |
||
AK5554VN |
MP |
4 |
Differential |
32 |
768 |
-106 |
115 (121*) |
4.5 |
5.0 |
5.5 |
VELVETSOUND, Automotive grade |
-40 to 105 |
HVQFN |
48 |
||
AK5558VN |
MP |
8 |
Differential |
32 |
768 |
-106 |
115 (124*) |
4.5 |
5.0 |
5.5 |
VELVETSOUND, Automotive grade |
-40 to 105 |
HVQFN |
64 |
||
AK5572EN |
MP |
2 |
Differential |
32 |
768 |
-112 |
121 (124*) |
4.75 |
5.00 |
5.25 |
VELVETSOUND |
-40 to 105 |
HVQFN |
48 |
||
AK5574EN |
MP |
4 |
Differential |
32 |
768 |
-112 |
121 (127*) |
4.75 |
5.00 |
5.25 |
VELVETSOUND |
-40 to 105 |
HVQFN |
48 |
||
AK5578EN |
MP |
8 |
Differential |
32 |
768 |
-112 |
121 (130*) |
4.75 |
5.00 |
5.25 |
VELVETSOUND |
-40 to 105 |
HVQFN |
64 |
||
AK5704EN |
MP |
4 |
Single / Differential |
32 |
192 |
-90 |
105 |
1.7 / 3.0 |
1.8 / 3.3 |
1.9 / 3.6 |
Yes |
Yes |
VAD, ALC, Cascade TDM I/F |
-40 to 85 |
HWQFN |
28 |
AK5704VN |
Preview |
4 |
Single / Differential |
32 |
192 |
-90 |
105 |
1.7 / 3.0 |
1.8 / 3.3 |
1.9 / 3.6 |
Yes |
Yes |
ALC, Cascade TDM I/F |
HWQFN |
28 |
|
AK5705ECB |
MP |
4 |
Single / Differential |
32 |
384 |
-87 |
109 |
1.7 / 3.0 |
1.8 / 3.3 |
1.9 / 3.6 |
Yes |
Yes |
Cascade TDM I/F |
-40 to 85 |
WLCSP |
25 |
AK5706ECB |
MP |
2 |
Single / Differential |
24 |
192 |
-90 |
105 |
1.7 / 3.0 |
1.8 / 3.3 |
1.9 / 3.6 |
Yes |
Yes |
AAA, Audio buffer, Cascade TDM I / F |
-40 to 85 |
WLCSP |
32 |
AK5707ECB |
MP |
1 |
Single / Differential |
16 |
48 |
-74 |
96 |
1.7 |
1.8 |
1.9 |
Yes |
Yes |
AAA, Audio buffer, Cascade TDM I/F |
-40 to 85 |
WLCSP |
16 |
AK5720ET |
NRND |
2 |
Single |
24 |
96 |
-94 |
102 |
2.7 |
3.0 or 5.0 |
5.5 |
Yes |
Cascade TDM I / F |
-40 to 105 |
TSSOP |
16 |
|
AK5720VT |
MP |
2 |
Single |
24 |
96 |
-94 |
102 |
2.7 |
3.0 or 5.0 |
5.5 |
Yes |
Cascade TDM I / F, Automotive grade |
-40 to 105 |
TSSOP |
16 |
|
AK5734VN |
MP |
4 |
Differential / Single |
24 |
192 |
-92 |
100 |
3.0 |
3.3 |
3.6 |
Yes |
Mic-diagnostics, Cascade TDM I/F, Automotive grade |
-40 to 105 |
HVQFN |
48 |
|
AK5736VN |
MP |
6 |
Differential / Single |
24 |
192 |
-92 |
100 |
3.0 |
3.3 |
3.6 |
Yes |
Mic-diagnostics, Cascade TDM I/F, Automotive grade |
-40 to 105 |
HVQFN |
48 |
[Notes] * Monaural Mode
