AK9255NK

EOL

Dual 16-bit 1.0MSPS ZDS-NS A / D Converter

Dual 16-bit 1.0MSPS ZDS-NS A / D Converter

EOL

Description

The AK9255NK is 16-bit 1.0 MSPS ZDS-NS A / D converter(※).
 This product is ZDS A / D converters with noise suppression function and capable of improving the system accuracy.
 The AK9255NK is available in a small package, saving space on the printing board.
 In addition, 14-bit option, AK9256NK and different output interface options, the AK9255ANK and the AK9256ANK, are also available.
(※) ZDS-NS | Zero latency Delta Sigma with Noise Suppression. ,
A ZDS-NS A / D converter realizes ultrafast response of SAR while maintaining high accuracy conversion like a delta-sigma converter, based on AKM’s accumulated experience and know-how in analog-digital LSI technology. A ZDS-NS A / D converter has smaller input capacitance than SARs, reducing the buffer load of the input stage of the IC. Furthermore, the oversampling process is executed inside of the IC, and the averaging process is carried out with a built-in digital filter. Therefore, analog input signal noise can be suppressed, contributing to improving noise characteristics of the system. It also contributes to high-speed processing of a system that needs a noise averaging.
(AKM is the Asahi Kasei Microdevices Corporation)

Key Features

  • Zero Latency Delta Sigm type modulation ADC with built-in noise suppression function.
  • High precision conversion, high speed response.

Applications

  •                                 Motor control equipment, etc.


Specifications

Part Number
AK9255NK
Number of Channels
2
Resolution [bit]
16
Speed [MSPS]
1
Power Supply Voltage (MIN.) [V]
3.0 / 3.0
Power Supply Voltage (TYP.) [V]
3.3 / 3.3
Power Supply Voltage (MAX.) [V]
3.6 / 3.6
Power Consumption [mW]
88
Control Interface
SPI
Package Size [mm(mm2)]
3x3 (9)
Other


Operating Temperature [℃]
-40 to 105
Device Package
HWQFN
Number of Pins
16

Product Information

Part Status
EOL
Pb Free
Yes
Halogen Free
Yes
MSL
MSL2
Packaging
TAPE
JEDEC Standard Packaging
Compliant
Minimum Order Quantity [pcs.]
1000
Replacement P/N



Block Diagram

Block Diagram
