FAQ - Hall Effect ICs

Hall Effect ICs

[Q0405]
・Which output is present at power on, H or L?
A.
・When the magnetic flux density is Bop or higher, it is L. When it is Brp or lower, it is H. When it is between Bop and Brp, it varies.
Was it helpful?
Yes
No
Thank you We will reflect your opinion on the improvement of the web content.
[Q0406]
・How fast the response speed (the duration from the magnetic flux density exceeds Bop to the time when the output changes) is?
A.
・It depends on the grade, but roughly estimated, it is 5 μs or less.
